China Concrete Pump Bend Pipe with Inside Bracket (5.0/ Dn125) factory and manufacturers

Concrete Pump Bend Pipe with Inside Bracket (5.0/ Dn125)

Port:	Tianjin, China
Production Capacity:	500PCS/Per Day
Payment Terms:	L/C, T/T, D/P, Western Union, Paypal, Money Gram

Model NO.

5.0/ Dn125

Theoretical Weight(Lbs/Kg)

51.7/23.5

Length Deviation

<+-1mm

Hardened Process UHF Quenching (400kHz)

UHF Quenching (400kHz)

Weld Tensile Strength

>580bar

Surface Coating

Baking Paint

Pressure Detection Rate

100%

Thickness

8/13mm

Center Line Radius in./mm

16/406

Angular Deviation

<1 Degree

Flange Tape

Sk148 HD157 Zx175 FM175

Color

Red Black White or Customized

Manufacture Process

Pushed/Quenched/Auto

Trademark

Ximai

Transport Package

Standard Export Packing

Specification

5.0/ Dn125

Origin

China

Supply High quality CONCRETE PUMP BEND PIPE WITH INSIDE BRACKET

CONCRETE PUMP BEND PIPE WITH INSIDE BRACKET
Part NO.	ODIn./DIN	Center Line RadiusIn./mm	Degree ofAngle	Theoreticalweight(lbs./kg.)
IBB801690	3.0/ DN80	16/406	90	30.8/14
IBB1001890	4.0/ DN100	18/610	90	47.3/21.5
IBB1254890	5.0/ DN125	88/1219	90	122/55.5
Any type of elbow can be customized
Any types of weld ends are available.METRIC (SK) WELD ENDSHEAVY DUTY WELD ENDSSCHWING F/M WELD ENDSPUTZMEISTER Z/X WELD ENDS
